0.75KW 3-Phase Alumium Housing 380V Electric Motor IE2 Energy-saving

The YE2 series electric motors offer versatile solutions with both cast iron and aluminum housing configurations to meet diverse industrial requirements. The cast iron variant (frame sizes 80-355) provides an economical solution with exceptional structural rigidity and vibration damping properties, making it ideal for heavy-duty applications. Alternatively, the aluminum housing option (frame sizes 80-132) delivers superior thermal management with 30% weight reduction, enhanced aesthetics, and removable mounting feet for flexible installation.

Engineered for optimal energy conservation, these motors achieve Class 3 efficiency under GB18613-2012 standards and comply with international IE2 efficiency classification per IEC60034-30. The advanced electromagnetic design incorporates high-grade silicon steel laminations and precision-balanced rotors, resulting in 15-20% energy savings compared to conventional motors while maintaining exceptionally low noise levels (<65dB) and minimal vibration.

Application versatility includes:

Fluid handling equipment (pumps, compressors)

HVAC systems (fans, blowers)

Industrial machinery (mixers, conveyors)

Agricultural processing equipment

Food production line machinery

Special design features include:

 IP55 protection grade for dust/moisture resistance

 F-class insulation for reliable thermal endurance

 Wide voltage tolerance (±10%) for unstable grids

 Non-sparking construction for safe operation

These motors are specifically excluded from hazardous environments containing flammable or corrosive substances. The aluminum version is particularly recommended for applications requiring frequent repositioning or weight-sensitive installations, while the cast iron model excels in high-torque, continuous operation scenarios.

Ambient air temperature: -15℃≤θ≤40℃

Altitude:≤1000m

Rated frequency: 50Hz/60Hz

Wiring method: Y wiring method for ≤3kw

△wiring method for ≥4kw

Working type: S1 (continuous working system)

Insulation class: F

Protection grade: IP54 or IP55

Cooling type: IC411
