3SDM 1.1KW Submersible Pump For Water Supply From Wells or Reservoirs Wholesale Price 3inch 220V

1.For water supply from wells or reservoirs.
2.For domestic use,for civil andindustrial applications.
3. For garden use and irrigation.

Product description

This engineered pumping solution delivers reliable performance across water supply, irrigation, and industrial fluid handling scenarios. Capable of operating at 80m submersion depths, it handles moderately sandy water (0.25% particulate content) within confined 4" diameter spaces while withstanding +35°C fluid temperatures. The motor selection encompasses both maintainable rewinding units and sealed permanent magnet designs, available in 50Hz three-phase (380-415V) or single-phase (220-240V) variants. System integration options include traditional electromechanical starters or modern microprocessor-based controllers with energy monitoring features. The pressure-optimized pump housing design allows for optional upgrades including industrial-grade mechanical seals and customized power configurations (60Hz/alternative voltages). Ideal for residential water wells, commercial building water systems, and extensive agricultural irrigation projects requiring durable, maintenance-conscious equipment.

4SD2

Application

1.For water supply from wells or reservoirs.

2.For domestic use,for civil andindustrial applications.

3. For garden use and irrigation.

Operating conditions

1.Maximum fluid temperatureup to +35℃

2.Maximum immersion:80m

3.Maximum sand content:0.25%

4.Minimum well diameter:4"。

Motor and Pump

1.Rewindable motoror Full obturatedscreen motor Three-phase:380V-415V/50Hz

Single-phase:220V-240V/50Hz

2.Equip with start control boxor digital auto-control box Pumps are designed by casing stressed

Options on request

1.Special mechanical seal

2.Other voltages or frequency 60 Hz

Specification

Model number	Voltage(V)	Frequency（HZ）	Rated power(KW)	Rated flow(m3/h)	Rated head(m)	Caliber	Rotational speed(r/min)
Model number	Voltage(V)	Frequency（HZ）	Rated power(KW)	Rated flow(m3/h)	Rated head(m)	Caliber	Rotational speed(r/min)
3SDM3-54/16-0.75	220	50	0.75	3	54	3寸	2850
3SDM3-82/24-1.1	220	50	1.1	3	82	3寸	2850
3SDM3-64/15-0.37	220	50	0.37	3	64	3寸	2850
3.5SDM2-52/11-0.37	220	50	0.37	2	52	3.5寸	2850
4SDM2-66/12-0.55	220	50	0.55	2	66	4寸	2850
4SDM2-77/14-0.75	220	50	0.75	2	77	4寸	2850
4SDM2-105/19-1.1	220	50	1.1	2	105	4寸	2850

FAQs

1.Q:Are you a manufactory or trading company?
A:we are a direct manufacturer. Taizhou Yide Pumps Co., Ltd. operates our own production facility and supply chain, specializing in fluid-handling solutions.
2.Q:Causes of abnormal current rise?
A：Bearing wear/voltage fluctuation/impeller rubbing
3.Q:Installation inspection interval?
A:First check at 100hrs, then full inspection every 6 months
