QDX Series 0.75kw Submersible sewage pumps for Dirty Water and Small Particles Handling
Submersible sewage pumps
Application
This durable pumping system excels in applications requiring transfer of particle-laden non-aggressive liquids, capable of processing solids with maximum 10mm spherical diameter. The corrosion-resistant materials selection allows safe operation with contaminated water including domestic sewage, construction site runoff, and industrial process water lacking chemical solvents. Its innovative impeller design combines high volumetric efficiency with exceptional solids-passing capability, making it particularly effective for emptying septic tanks, drainage sumps, and floodwater collection basins. The pump's reliability stems from its heavy-duty mechanical seal system and abrasion-resistant volute casing, engineered for extended service life in demanding environments. User-centric features include tool-free access for clearing potential blockages and universal mounting options for both stationary and portable installations.
Motor
Operating conditions
ComponentConstruction
Specification
| Model number | Voltage (V) | Frequency (HZ) | Rated power (KW) | Maximum flow (m3/h) | Maximum lift (m) | Rated current (A) | Maximum suction (m) | Diameter (mm) | Speed (r/min) |
| QDX1.5-16-0.37 | 220 | 50 | 0.37 | 3 | 16 | 2.5 | 25 | 2850 | |
| QDX1.5-32-0.75 | 220 | 50 | 0.75 | 5.4 | 32 | 4.8 | 25 | 2850 | |
| QDX10-16-0.75 | 220 | 50 | 0.75 | 16.2 | 16 | 4.8 | 50 | 2850 |
FAQs
1.Q:Can you ship to my country’s port?
A: We ship globally – specify your preferred port.
2.Q: Can you comply with our local standards?
A: Yes – inform us of requirements (e.g., CSA for Canada).
3.Q : What's the payment term?
A: We accept T/T, L/C,, etc.
